Filtration & Pumps — Your Complete Guide to Pool Circulation Systems

What is a pool filtration system?

A pool filtration system moves water through a skimmer and pump into a filter (sand, cartridge, or DE) to remove debris and contaminants, then returns clean water back to the pool. Choosing the right filter and pump depends on pool size, turnover target, and maintenance preference.

​

This Filtration & Pumps hub explains how each system works, which setups suit above-ground vs in-ground pools, and links to top product reviews and tools so you can pick the perfect system.

​

​​

Quick Snapshot: Which Pool Filtration System Is Right for Your Pool?

​Choosing the right pool filtration system depends on your pool size, maintenance preference, and water clarity goals. Most residential pools use one of three filter types: sand filters, cartridge filters, or DE filters. Each has its own advantages depending on how much maintenance you want and how clear you want your pool water to be.​

​

Sand Filters



Best for pool owners who want simple maintenance and easy backwashing. Sand filters are durable and commonly used in above-ground pool filtration systems.

Example system: Hayward ProSeries Sand Filter

​​

Cartridge Filters

​

Best for pool owners who want clearer water and lower water waste, since cartridge filters do not require backwashing.


Example system:  Hayward XStream Cartridge Filter

​​

​

DE Filters

​

Best for pool owners who want maximum water clarity, though they require more maintenance than sand or cartridge systems.


Example system: Hayward Perflex DE Filter

​

​

​How Pool Filtration Systems Work

A pool filtration system moves water from the pool, through a skimmer and pump, into a filtration medium (sand, cartridge or DE) to remove debris and contaminants, and then returns clean water back to the pool. Understanding the flow, components, and basic metrics (flow rate, head, and turnover) helps you pick the right pump and filter — and keeps your water clear with less fuss!

​

Skimmer → Pump → Filter → Return: the flow explained

​

​

• Skimmer: First stop. Surface skimmers capture leaves and floating debris before water reaches the pump.

• Pump: The system’s heart — it pulls water from the skimmer and pushes it through the filter. The pump determines how fast water moves (GPH/GPM).

• Filter: Removes particles. Sand filters trap larger debris and are backwashed; cartridge filters (like a Hayward cartridge filter for pool systems) trap finer particles and are rinsed; DE filters provide the finest filtration.

• Return: Clean water is sent back through return jets; good return flow ensures even circulation and chemical distribution.

Think of the system as a loop — skim, push, clean, and return.

​

Key components and what each one does

​

• Skimmer & skimmer basket — captures big debris; empty it frequently.

• Pump & strainer basket — circulates water; check and clean the strainer basket.

• Filter tank & media (sand/cartridge/DE) — the actual filtration stage. Example: a Hayward cartridge filter collects fine particles without backwashing.

• Multiport valve / VariFlo / control valve — directs flow for filter/backwash/rinse/waste.

• Pressure gauge — tells you when the filter needs cleaning (see rules below).

• Unions, pipes, and fittings — plumbing that connects everything; pipe diameter affects flow and head.

• Heater, chlorinator, cleaner lines (optional) — added equipment that can affect system head and flow.

​

​

Flow, head and turnover — the basics!

​

Pool systems aim for a full water turnover every 8–10 hours. Turnover = pool volume ÷ desired hours. Head is the system resistance that reduces pump flow. For detailed pump curves, friction loss calculations and step-by-step sizing, see our Pool Filtration & Pump Sizing Guide.

​

​👉 Read the full sizing guide → Filtration & Pumps Guide

​

​

Common filter maintenance signals (quick checklist)

​​

• Pressure gauge up 5–8 PSI over clean reading → clean cartridge / backwash sand.

• Noticeable drop in return flow → check skimmer and pump basket.

• Water getting cloudy between cleanings → consider finer media (cartridge or DE) or longer run times.

• Sand older than 3–5 years → consider replacing sand.

​

​

Practical tips for matching pump & filter

​​

• Use the pool volume calculator first to get gallons.

• Aim for an 8–10 hour turnover; pick pump/pipe sizes that hit the required GPM at realistic head.

• For energy savings, consider a variable speed pump (runs slower for longer periods).

• Keep unions and valves accessible for easy maintenance.

​

A correctly balanced pool filtration system skims surface debris, pumps water through the filter media (sand/cartridge/DE), and returns clean water, with the target being a full turnover every 8–10 hours.​



Understanding Pool Filter Types: Sand vs Cartridge vs DE

​Most residential pool filtration systems use one of three filter types: sand filters, cartridge filters, or diatomaceous earth (DE) filters. Each type removes debris and contaminants differently and requires different levels of maintenance.

​

Sand filters

Sand filters work by pushing water through specially graded pool filter sand inside a tank. The sand traps dirt and debris as water passes through it.

​

These filters are popular because they are simple to maintain and easy to clean using a backwash valve.

Example: Hayward ProSeries Sand Filter.

Cartridge filters

Cartridge filters use a pleated filtration cartridge that captures smaller particles than many sand filters. Because of the large surface area of the cartridge, water can flow through while trapping fine debris.

​

Instead of backwashing, the cartridge is removed and rinsed with a garden hose.

Example: Hayward XStream Cartridge Filter.

DE filters

DE filters use a powder made from fossilized algae called diatomaceous earth. This powder coats internal filter grids and traps extremely small particles.

​

They provide the highest level of filtration, but require more maintenance and careful handling of the DE powder.

Example: Hayward Perflex DE Filter.

​

Best Pool Filtration Systems for Above-Ground Pools

If you're upgrading your pool equipment or replacing an old filter system, the following filtration setups are reliable, easy to maintain, and well suited for most above-ground pools.

​​​​

 BEST SAND FILTER

​

​

​

​









​



​

Hayward ProSeries 18" Sand Filter System

​

Reliable, low-maintenance sand system with a matched 1-HP pump — great for most above-ground pools that need dependable circulation and simple backwashing.

​

Best for: above-ground up to ~20k gal

Filter type: Sand

Maintenance: Low (backwash)



​



_________________________________________________________​​​

​​​

 BEST CARTRIDGE FILTER

​

​

​

​





​

​

​​

​

Hayward XStream Cartridge Filter System

​

High-capacity cartridge system (100–150 sq ft options) that delivers finer filtration and longer run times between cleanings — ideal for owners wanting clearer water without backwashing.

​

Best for: clarity & water conservation

Filter type: Cartridge

Maintenance: Medium (periodic rinse)



​

​_________________________________________________________

​

 BEST VARIABLE SPEED PUMP

​​

​

​

​

​

​

​

​

​​

​​

​​​​

Aquastrong Variable Speed Pool Pump (1.5 HP option)​

​​

Smart variable-speed pump that lets you run long, low-speed filtration cycles for big energy savings while maintaining excellent turnover and flexibility for different pool setups.

Best for: energy savings & flexible flow

Pump type: Variable speed

Savings: up to ~80% vs single speed (depending on run time)

​​​​​​​​​​

​

​

​_________________________________________________________​​

​

 BEST MID-RANGE SAND

​​

​

​

​

​

​

​

​

​

​​​

Intex SX2800 Sand Filter Pump​

​

Popular mid-range sand filter pump that’s an easy upgrade for many above-ground pools — stronger flow and reliable sand filtration without complicated installation.

Best for: mid-size above-ground pools

Filter type: Sand

Maintenance: Low (backwash)



​


_________________________________________________________​​​

​​

 BEST ENTRY CARTRIDGE

​

​

​

​​

​

​

​

​

​

Intex 1000 GPH Cartridge Filter Pump

​

Affordable, easy-to-install cartridge pump for smaller above-ground pools — low upfront cost and simple cartridge maintenance for light-use pools.

Best for: small pools & budget installs

Filter type: Cartridge

Maintenance: Medium (hose rinse)

​

​

_________________________________________________________​​

​​​​​​​

 BEST BUDGET SAND FILTER

​​

​​

​

​

​

​

​​

​

​

XtremePowerUS 13" Sand Filter Pump

​

A widely purchased budget sand filter option on Amazon — good value for small-to-medium above-ground pools when you need a reliable, low-cost sand solution.

Best for: budget-conscious buyers

Filter type: Sand

Maintenance: Low (backwash)

​

​​​​​​​​​

​



​

​

Pool Filtration Sizing Guide

Choosing the correct pump and filter size is essential for efficient operation. Our detailed Pool Filtration & Pump Sizing Guide walks you through turnover math, pump curve basics, and how to match pump GPM to filter capacity.



Use the Pool Volume Calculator first, then follow the guide.


👉 Read the full sizing guide → Filtration & Pumps Guide

​

​Common Pool Filtration Problems and How to Fix Them



Cloudy Pool Water

If your pool water looks cloudy, the filtration system may not be circulating water long enough or the filter may need cleaning.

Possible solutions:

​

• Clean or backwash the pool filter

• Run the pump longer (8–10 hours per day)

• Check that the pump and filter are properly sized for your pool

​

Weak Water Flow From Return Jets

Low circulation often indicates a clogged filter, dirty skimmer basket, or partially blocked pump impeller.

Possible solutions:

​

• Clean the skimmer basket

• Check the pump strainer basket

• Clean or replace the filter cartridge

​

Filter Pressure Too High

High pressure readings on the filter gauge usually mean the filter media is dirty or clogged.

Possible solutions:

​

• Backwash a sand filter

• Clean a cartridge filter

• Inspect hoses or plumbing for blockages

​

Pool Debris Returning to the Water

If dirt or debris is returning to the pool, the filter media may be worn out.

Possible solutions:

​

• Replace old filter cartridges

• Replace sand that has been used for several seasons

• Inspect the filter for internal damage

​​

​

FAQ About Pool Filtration Systems



What type of pool filter is best for above-ground pools?

Sand filters are one of the most common options for above-ground pools because they are simple to maintain and easy to clean using a backwash valve. Cartridge filters are another popular choice because they provide finer filtration and do not require backwashing.

​

How long should I run my pool pump each day?

Most pools should run their filtration system long enough to circulate all of the pool water at least once every 8 to 10 hours. The exact runtime depends on pool size, pump flow rate, and how often the pool is used.

​

How often should a pool filter be cleaned?

Cleaning frequency depends on the type of filter. Sand filters typically require periodic backwashing, while cartridge filters should be rinsed when the filter pressure increases about 5–8 PSI above the normal operating pressure.

​

What size pool filter do I need?

The correct filter size depends on your pool volume and the pump’s flow rate. Larger filters generally allow longer filtration cycles and require less frequent cleaning.

​

What is the difference between a sand filter and a cartridge filter?

Sand filters push water through filter sand to trap debris, while cartridge filters use a pleated cartridge that captures smaller particles. Cartridge filters typically provide finer filtration but require manual cleaning instead of backwashing.​​
